    Door Access Control Automatic Swing Gate

    Ask Lasest Price
    Brand Name : WEJOIN
    Model Number : WJTB201
    Certification : CE, ISO,
    Price : negotiation
    Payment Terms : T/T
    Supply Ability : 150pcs/week
    Delivery Time : 5-10 days
    • Product Details
    • Company Profile

    Door Access Control Automatic Swing Gate


    Door Access Control Security Swing Gate , Multi Lane Full Auto Swing Barrier For Factory


    Door Access Control Gate Multi Lane Full Auto Swing Barrier for Factory


    Specifications

    Model Item
    Swing Barrier Mechanism
    Mechanism Dimension108*450mm
    Arm Length(Optional)500-900mm
    Motor MaterialSteel and Aluminum Alloy
    Driving Motor24V Brush DC Motor
    Swing DirectionSingle or Bidirectional Operation are Available
    Input InterfaceDry Contact and Switch Signal Connection
    Time for Opening or Closing1 second
    Starting time after power on3 seconds
    Transit Speed30~40 persons/min
    Working EnvironmentIndoor / Outdoor (Shelter)
    Working Temperature—25°C~50°C
    Relative Humidity

    ≤90%, no condensation

    Vertical Automatic Swing Gate with 304 Stainless Steel , Anti - bumping Function


    Quick Detail:

    • Name: Swing Barrier gate
    • Application: Business buliding
    • Material: Stainless steel
    • Feature: Adjustable access directions
    • Voltage: 110V/220V
    • Certificate: CE,ISO
    • Flow speed:30-40 people per minute
    • Opening time:1s
    • Arm length:500~900mm



    Description:


    1. WEJOIN swing barriers have automatic detection for malfunctions, which will be convenient for customer to maintain and operate.

    2. Secondly, WEJOIN swing barriers have a compact electro-mechanical design with unique drive which ensure product durability and silent operation, and its self-lock mechanism can also well protect the access control security.

    3. Thirdly, WEJOIN swing barriers have input interface that are available for dry contact and switch signal connections. So that customers can integrate the swing barrier with different system, like card reader, ticket system, token system etc.

    4. Fourthly, WEJOIN swing barriers have auto delay closing function, after the flaps open if no pedestrian passes in a fixed time, the system will cancel the order and the auto-delay closing time is adjustable.

    5. Fifthly, WEJOIN swing barriers Alarm for unauthorized access and no accee against passenger flow

    6. Sixthly, WEJOIN swing barriers can be integrated with traffic light indicating passenger access


    Quick Detail

    • Model:WJTB101
    • Application:Access control System
    • Housing Material: Stainless Steel
    • Feature: Compatible with IC/ID/bar code,etc
    • Voltage:AC110V/220V
    • Certificate:ISO,SGS



    Door Access Control Automatic Swing GateDoor Access Control Automatic Swing Gate



    Certificates


    WEJOIN Manufacturing Technique
