    1800KG Heavy duty sliding gate motor manufacturers with gear rack

    Ask Lasest Price
    Brand Name : WEJOIN
    Model Number : WJMP202
    Certification : CE,ISO,SGS
    Price : USD 150-200 SET
    Supply Ability : 10000 set / month
    • Product Details
    • Company Profile

    1800KG Heavy duty sliding gate motor manufacturers with gear rack

    1800KG Heavy duty sliding gate motor manufacturers with gear rack


    Function and Features
    1. Integrated structure of the mechanic and electron. No need to install other controllers.
    2. Electronic soft-start.
    3. Automatically restraining when meets obstacle.
    4. Crash proof and automatically restraining socket.

    5. Crash proof (photocell).
    6. Alarm light socket.
    7. Line control and Remote control are optional.
    8. Intelligent automatic heating function.
    9. Automatically increase the temperature when the temperature is below 0 degree.


    Motor Data

    Model: KMP202

    Voltage: 220V±10%, 110V±10%

    Frequency: 50/60Hz

    Current: 2.7A, 5.8A

    Motor voltage: AC 220V/110V

    Capacitor: (220V) 20µF, 60µF+14µF

    Power: 350W

    Torque: 35nm

    Motor number: M=4

    Motor speed: 1350rpm, 1620rpm

    Gear speed: 58.8rpm, 70.2rpm

    Travel speed: 11m/min, 13.2m/min

    Working temperature: -40°c~ 55°c

    Overload protection temperature: 130

    Relative humidity: ≤90%

    Motor making technique: die casting aluminum alloy

    Manual Release: yes

    Remote distance: >30m

    Product weight, approx: 10.19kg, 10.25kg

    Max, weight of gate: 1800kg


    Electronic Data

    Model

    KMP202

    Soft start

    YES

    Stop on obstacle (sensitivity adjustable)

    YES

    Auto warming-up (at freezing temperature)

    YES

    Remote control

    418MHz (50m, approx)

    Wire control

    Available

    Auto closing

    YES

    Vehicle loop detector socket

    YES

    Photocell socket

    YES

    Alarm light socket

    YES


    Motor base and it's installation

    1. Motor base installation: set the installation position of the base tray according to the size of the motor and the height of the installation position of the gear rack. Then Embed the bolts in advanced or use the expansion bolts to embed the base into the cement foundation.
    2. If the gear rack has already been installed, fix the motor to th base and turn the clutch with the clutch key to the off position, then make the gear of the motor suit right to the gear rack, then the position of the base can be set. Take off the motor and fix the base.
