    Wing 600mm SST 304 Full automatic Flap Turnstile Barrier Gate

    Ask Lasest Price
    Brand Name : WEJOIN
    Model Number : WJTY600
    Certification : CE,ISO
    Price : Negotiation
    Payment Terms : T/T, Western Union
    Supply Ability : 50pcs/week
    Delivery Time : 10-30days
    • Product Details
    • Company Profile

    Wing 600mm SST 304 Full automatic Flap Turnstile Barrier Gate

    Wing 600mm SST 304 Full automatic Flap Turnstile Barrier Gate

    Function& Feature:
    1.Equipped with a standard input/output signal interface, can be integrated with all types of the access control panel, offering complete entrance control solutions.

    2. Anti-collision function, the flaps will stay close if not receiving the open signal.
    3.Flaps open on power failure. It can be integrated with a Fire alarm system or other alarming signals for emergencies. It will open automatically in case of an emergency.
    4.Flaps reset to lock position when access time expires.
    5.Prevents Invalid/Tailgate/Wrong direction access.
    6.LED Array indication for an access granted/denied.
    7. Compatible with diverse access control devices.
    8. Pedestrian flow directions can be single or double directions.

    Technical data :

    Model
    Item

    WJTY202WJTY301WJTY311
    Material of Housing304 Stainless Steel
    The material of Flap DoorOrganic Glass, Resin, or PVC
    Dimension of housing1200*270*10001450*315*10201400*305*1020
    Thickness of housing1.5mm
    Max Width of Passage600900900
    Net weight70kg140 kg85 kg
    Normal Life Span3 million times
    Communication InterfaceStandard RS485(distance less than 1200 meters)
    Transit speed30-40 persons/min
    Power supply220V±10%, 110± 10%
    Frequency50/60HZ
    The working voltage of the motorDC24V
    Time for opening or closing1s
    Starting time after power on3s
    Input interface

    Dry contact signal or +12Vor pulse
    signal with width more than
    100ms DC12V

    Transit speed25~32 persons/min
    Working temperature-10°C~50°C
    Working environmentIndoor / Outdoor (Shelter)
    Relative humidity≤95%, no condensation

    Wing 600mm SST 304 Full automatic Flap Turnstile Barrier Gate
