    No Spring And Round Hollow Out Design Electric Car Park Swing Gate DC Variable Frequency

    Ask Lasest Price
    Brand Name : WEJOIN
    Model Number : SCB02
    Certification : CE ISO SGS
    Price : negotiation
    Payment Terms : T/T, Western Union
    Supply Ability : 10000 sets/month
    Delivery Time : 12 working days after payment received
    • Product Details
    • Company Profile

    No Spring And Round Hollow Out Design Electric Car Park Swing Gate DC Variable Frequency

    No spring and Round Hollow-out design DC Variable-Frequency Barrier Gate


    Boom Barrier Brief Introduction

    1. The cabinet is round hollow-out design, with smooth lines and intuitive movement process.
    2. Equipped with carbon fiber foam round boom, to effectively protect the vehicle.

    3. Large LCD screen display, English visual menu, easy function selection and debugging.

    4. Support external radar, coil, infrared anti-smashing function, built-in DC 12V power output, can be used for external radar power supply.

    5. Support RS485 communication or RS485 off-line connection.

    6. DC12V power supply is optional.


    Parking Barrier Common Malfunctions and Solutions

    Malfunction PhenomenonPossible CausesSolution
    The swing direction of the boom does not match the actual directionThe motor rotation direction setting is wrongRefer to 2.1 to set the rotation direction of the master and slave motors
    The boom is automatically lifted up after falls to the horizontal positionThe retraction value of the main motor 4.5 in the closing to limit position is too large, or the mechanical limit adjusting bolt in the closing direction is extended to too muchReduce the retraction value of the main motor 4.5 in the closing to limit, or readjust the mechanical limit adjusting bolt

    Barrier Gate Technical Data

    1. Working temperature (motor): -35℃~ + 70℃

    2. Power supply input voltage: AC110±10%, AC220V±10%

    3. Controller input voltage: DC24V±10%, 10A

    4. Motor power: up and down power 180W; horizontal power 60W

    5. Relative Humidity: 30%~80%, No condensation

    6. Distance of remote control: L≥30M

    7. Running Speed: 0.3 seconds MAX

    8. MTBF: 8,000,000 times


    No Spring And Round Hollow Out Design Electric Car Park Swing Gate DC Variable Frequency
