    Automatic car barrier drop-arm barrier gate remote control packing barrier

    Ask Lasest Price
    Brand Name : WEJOIN
    Model Number : CB01SV
    Certification : CE ISO SGS
    Price : negotiation
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 10000 sets/month
    Delivery Time : 12 working days after payment received
    • Product Details
    • Company Profile

    Automatic car barrier drop-arm barrier gate remote control packing barrier

    Automatic car barrier drop-arm barrier gate remote control packing barrier


    Vehicle Barrier Gate Quick Detail:

    The technology is applied to drive motor of electric vehicle and spindle motor of CNC lathe.

    # Strong moment, high precision control, low temperature rise

    # Standard traffic lights

    # 1-2s/3-5s speed adjustable

    # gold, black and orange color optional


    Vehicle Barrier Gate Brief Introduction:

    This is our newly-produced DC servo barrier gate, which utilizes the updated electronic control technology and machinery processing technology, no limit switch design, to realize non-adjust of mechanism, adjustable speed, automatic speed reduction, ext. In this way, make the barrier operate more steadily and more reliably. This product is highlighted in frequency applications and longer lifetime.

    Vehicle Barrier Gate Functions & Features

    1). DC permanent magnet synchronous motor(PMSM), servo control.
    2). The motor has the same performance as the main motor of the CNC machine tool and the electric vehicle motor, it has high control precision, high torque density, good torque balance, low power conaumption, high efficiency and low noise.
    3). Bi-direction boom holder design: left-installation and right-installation can be exchanged easily and quickly.
    4). Manual clutch design: when power-of, turn the handwheel a little, then move the boom by hand.
    5). Double tension spring crank transmission design, for more stable and reliable structure.
    6). No limit switch design, accurate encoder detection, detecting boom position when power on. And open/close speed is adjustable.
    7). More sensitive and reacting faster when reversing on obstacles.
    8). With counting, delay auto-closing, and auto-aging test function.
    9). 4-digit digital tube display, displays more information.
    10). NO/NC wire control signal input are optional.
    11). Integrated RS485 communication, infrared photocell and loop detector interface. RJ45 network, loop detector, and radar module can be added.


    Vehicle Barrier Gate Technical Data

    Model

    WJCB01SV-H

    WJCB01SV-I

    Running Speed

    1/1.5/2S

    3/4/5S

    5S

    5S

    5S

    5S

    Boom Type

    Straight

    Straight

    90° Folding

    180° Folding

    2 Fence

    3 Fence

    Max Boom Length

    3.5M~4.5M

    4.5M~6M

    5M

    4M

    4.5M

    4M

    Input Voltage

    AC220V±10%, AC110V±10%

    Frequency

    50/60HZ

    Motor Voltage

    DC310V

    Enclosure Rating

    IP54

    Working Temperature

    -35°C ~ +85°C

    MTBF

    6000000 times

    Traffic Flow Appication

    24 hours uninterrupted operation

    Max Motor Power

    150W

    Max Motor Speed

    36r/min

    Max Torque

    240N.m


    Automatic car barrier drop-arm barrier gate remote control packing barrier
