Easy Operated Auto Parking Lot Gate Control Systems For Outdoor Parking Area

Shenzhen Wejoin Mechanical & Electrical Co.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Easy Operated Auto Parking Lot Gate Control Systems For Outdoor Parking Area from wholesalers

    Buy cheap Easy Operated Auto Parking Lot Gate Control Systems For Outdoor Parking Area from wholesalers
    • Buy cheap Easy Operated Auto Parking Lot Gate Control Systems For Outdoor Parking Area from wholesalers

    Easy Operated Auto Parking Lot Gate Control Systems For Outdoor Parking Area

    Ask Lasest Price
    Brand Name : WEJOIN
    Model Number : WJDZ04SV
    Certification : CE ISO SGS
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 10000 sets/month
    Delivery Time : 3-5 working days after payment received
    • Product Details
    • Company Profile

    Easy Operated Auto Parking Lot Gate Control Systems For Outdoor Parking Area

    Automatic car parking lot access control entrance boom barrier gate


    Quick Detail

    WEJOIN Mid-Grade Servo Barrier Gate WJDZ04SV

    DC Brushless Servo Motor

    Higher Stability, Longer Service Life


    Parking Barrier Gate Brief Introduction
    Newly-produced DC servo barrier gate, which utilizes the updated electronic control technology and machinery processing technology, no limit switch design, to realize non-adjust of mechanism, adjustable speed, automatic speed reduction, ext. In this way, make the barrier operate more steadily and more reliably.


    WEJOIN Main Advantages

    1. Global leading manufacturer for barrier gate.

    2. Mater of core technology and innovation.

    3. Intelligent quality manufacture and automatic flexible production.

    4. Global advanced manufacturing process and testing equipment.

    5. Servo, bi-direction motor and other leading technique.


    Parking Barrier Gate Application

    Suitable for indoor as well as outdoor parking area
    Parking lots, goods yard, railway crossing, commercial premises, apartment block access shopping malls,
    hospitals, stadiums, business centers,etc.


    Parking Barrier Gate Functions
    1). Manual clutch design: when power-of, turn the handwheel a little, then move the boom by hand.
    2). Double tension spring crank transmission design, for more stable and reliable structure.
    3). No limit switch design, accurate encoder detection, detecting boom position when power on. And open/close speed is adjustable.
    4). More sensitive and reacting faster when reversing on obstacles.
    5). With counting, delay auto-closing, and auto-aging test function.
    6). 4-digit digital tube display, displays more information.
    7). NO/NC wire control signal input are optional.
    8). Integrated RS485 communication, infrared photocell and loop detector interface. RJ45 network, loop detector, and radar module can be added.


    Parking Barrier Gate Technical Data

    Model

    WJDZ04SV1 (speed 3~5s adjustable)

    Running Speed

    3S

    4S

    5S

    5S

    5S

    5S

    Boom Type

    Straight

    Straight

    Straight

    90° Folding

    2 Fence

    3 Fence

    Max Boom Length

    4.5M

    5M

    6M

    5M

    4.5M

    4M

    Model

    WJDZ04SV2 (speed 1.5~5s adjustable)

    Running Speed

    1.5s

    2/3/4/5s

    5s

    5s

    5s

    Boom Type

    Straight

    Straight

    90° Folding

    2 Fence

    3 Fence

    Max Boom Length

    3.5m

    4.5m-6m

    4m

    4.5m

    4m

    Housing Dimension

    362*325*1030mm

    Input Voltage

    AC220V±10%,AC110V±10%

    Frequency

    50/60HZ

    Motor Voltage

    DC310V

    Enclosure Rating

    IP54

    Working Temperature

    -35°C~+85°C

    MTBF

    5000000 times

    Traffic Flow Application

    3000 times/24hours

    Max Motor Power

    150W

    Max Motor Speed

    24r/min

    Max Torque

    240N.m


    Parking Barrier Gate Packing List

    Name

    Specification

    Quantity

    Unit

    Application

    Screw, Nuts, Flat Pad

    M12*70

    2

    sets

    Fixing the boom

    Boom Fixing Bar


    1

    pcs

    Fixing the boom

    Boom Holder Plastic Cover


    1

    sets

    Optional

    Cabinet Fixing Bar


    2

    pcs

    Fixing the boom

    Expansion Screws

    M16*150

    4

    sets

    Fixing the boom

    Support Post


    1

    pcs

    Optional

    Radio Emitter


    1

    pcs

    Optional

    Keys


    2

    pcs

    For cabinet door

    Remote Controller


    2

    pcs


    Manual


    1

    pcs


    Easy Operated Auto Parking Lot Gate Control Systems For Outdoor Parking Area
